RCA45T remote control pulse valve
Goyen remote control pulse valves are widely used in dust collection systems and other industrial applications where precise control of airflow is required. These valves are known for their reliability and efficiency in delivering short bursts of air to clean filters or control the flow of materials.
The RCA45T is a 1 1/2 inch port size remote controll pulse valve. It is remote control by the pilot valve and commonly used in dust collection and filtration systems in industrial applications.
It is equipped with a diaphragm that controls the pulsating air flow into the valve. The diaphragm open and close creating a pressure differential to effectively clean the filter and remove accumulated dust.
This 1 1/2 inch pulse valve is operated remotely. This allows easy integration into larger dust extraction systems and enables efficient, automated cleaning cycles. 1-inch size makes it ideal for applications where space is limited.
Outlet of RCA45T remote control pulse valve, it's 1 1/2” as you can see
Construction
Body: Aluminium (diecast)
Ferrule: 304 SS
Armature: 430FR SS
Seals: Nitrile or Viton (reinforced)
Spring: 304 SS
Screws: 302 SSDiaphragm Material: NBR / Viton
Installation
When installing an impulse valve, there are a few important considerations to keep in mind:
Installation location: Make sure the pulse valve is installed in the correct location specified by the manufacturer. Mounting in the wrong position will affect its performance and may cause malfunction.
Connections: Use the appropriate fittings to securely connect the pulse valve to the pneumatic system and make sure there are no air leaks. Any leaks will reduce the efficiency of the cleaning cycle.
Air source: Provide clean and dry air source for the pulse valve. Moisture or contaminants in the air can damage the valve and affect its performance.
Working Pressure: Set the working pressure within the recommended range specified by the manufacturer. Operating the valve at pressures that are too high or too low may result in ineffective cleaning or damage to the valve.
Electrical connection: Make sure that the electrical wires of the pulse valve are properly connected to the control system or remote control equipment. Incorrect wiring may cause valve malfunction or failure.
Filter Cleaning: Make sure the pulse valve is properly synchronized with the filter cleaning cycle. This involves setting the correct times and intervals at which the valves open and close to allow effective filter cleaning.
Regular maintenance: Regular maintenance is performed on the pulse valve to keep it clean and in good working condition. This includes checking for any signs of wear or damage, cleaning or replacing the diaphragm if necessary, and lubricating any moving parts according to the manufacturer's recommendations. By following these installation guidelines and performing regular maintenance, you can ensure efficient and reliable operation of your pulse valve in your dust collection system.
Type | Orifice | Port Size | Diaphragm | KV/CV |
CA/RCA20T | 20 | 3/4" | 1 | 12/14 |
CA/RCA25T | 25 | 1" | 1 | 20/23 |
CA/RCA35T | 35 | 1 1/4" | 2 | 36/42 |
CA/RCA45T | 45 | 1 1/2" | 2 | 44/51 |
CA/RCA50T | 50 | 2" | 2 | 91/106 |
CA/RCA62T | 62 | 2 1/2" | 2 | 117/136 |
CA/RCA76T | 76 | 3 | 2 | 144/167 |
RCA45T pulse valve membrane
Good quality imported diaphragm shall be selected and used for all the valves, with each part checked in each manufacturing procedure, and put into the assembly line conforming to all the procedures. Ever finished valve shall be taken blowing test.
Diaphragm repair kits suit for DMF series dust collector diaphragm valve
Temperature Range: -40 – 120C ( Nitrile material diaphragm and seal), -29 – 232C (Viton material diaphragm and seal)
Loading time: 7-10 days after payment received
Warranty: Our pulse valve warranty is 1.5 year, all valves comes with basic 1.5 year sellers warranty, if item defective in 1.5 year, We will offer replacement without extra charger(including shipping fee) after we receive the defective products.
Deliver
1. We will arrange deliver immediately after payment when we have storage.
2. We will prepare the goods after confirmed in the contract on time, and deliver ASAP follow the contract exactly when the goods are customized
3. We have a variety of ways to send goods, such as by sea, by air, express as DHL, Fedex, TNT and so on. We also accept deliver arranged by customers.
We promise and our advantages:
1. We are a factory professional for pulse valve and diaphragm kits manufacturing.
2. Our sale and technical team keep giving professional suggestions in first time when our customers have
any questions about our products and service.
3. We will suggest most convenient and economic way for deliver if you need, we can use our long term cooperation
forwarder to service based on your needs.
4. Every pulse valves have been tested before left our factory, make sure each valves come to our customers are good function without problems.
